Biosafety cabinet

External Size (W×D×H)(mm) 1050×780×2130
Work Area Size (W×D×H)(mm) 950×626×600
Tested Opening Safety height 200mm
Max.Opening 400mm
Work Surface Height 800mm
Control System Display 7” LCD touch screen
Alarm Abnormal airflow velocity, ULPA filter failure, UV lamp failure, Front window at unsafe height
Airflow System Airflow Mode 70% air recirculation、30% air exhaust
Downward Velocity 0.35m/s±0.025m/s
Inflow Airflow Velocity 0.52m/s±0.025m/s
Inflow Air Volume 355m³/h（209CFM）
Downflow Air Volume 718m³/h（423CFM）
Exhaust Air Volume 355m³/h（209CFM）
Air Filtration System ULPA Filter 2pcs ULPA filter, ≥99.9995% efficiency at 0.1~0.3 μm, filter life indicator
Cleanliness Grade Class 10 (ISO14644.1 Class 4)
Exhaust Filter Specification (mm)/Quantity 455×375×69×1pcs
Supply Filter Specifications (mm)/Quantity 896×506×69×1pcs
Cabinet Construction Main Body Electro-galvanized steel with antimicrobial Powder Coating
Work Surface 304 stainless steel
Front Window Motorized, Two-layer laminated toughened glass ≥ 5mm,Anti UV
Electrical System UV Lamp 20W×1，Emission of 253.7 nanometers for most efficient decontamination,UV life indicator, UV timer
LED Lamp 16W×2
Max.Consumption 750W(Not include socket loading power consumption)
Power Supply AC 220V,50/60Hzz; 110V, 60Hz
Cabinet Anti-leakage Apply pressure to 500 Pa and maintain for 30 minutes, The pressure should not drop below 450 Pa
Personnel Protection Impact sampling colony count≤10CFU per time；
Count of colonies in the slit sampler≤5CFU per time
Product Protection The number of microbial colonies is ≤ 5CFU per time
Cross-contamination Prevention The number of microbial colonies is ≤ 2CFU per time
Electrical Safety Dielectric Strength Basic insulation1390V, Enhanced insulation2224V
Grounding Resistance ≤0.2Ω
Illumination ≥1000Lux
Noise ≤62dB（A）
Vibration ≤2μm
Standard Accessory 1.Base Stand; 2. Air Velocity Sensor; 3. ULPA Filter; 4. LCD Touch Screen; 5. LED Lamp×2;
6.UV Lamp×1; 7. Waterprof Socket×2; 8. Motorized Front Window; 9. Footmaster Caster;
10. Foot Switch; 11. Electric Air Valve Control; 12. RS485 interface

Optional Accessory 1.LED Lights With Adjustable Brightness; 2. Gas Tap; 3. Water Tap; 4. IV Bar With Hooks;
5. Manual Adjustable Base Stand
Net Weight /Gross Weight (kg) 224/310
Shipping Size (WxDxH)(mm) 1170×1100×1620
Shipping Volume (m³) 2.2
